Elastic Tape Fatigue Testing Machine

item No: SL-LC61

Technical parameters of Elastic Tape Fatigue Testing Machine

Speed

65+/- 5 rpm

Stroke of movable grip

0~200 mm

Grip width

140mm

Timer

LCD Display 0~999,999

Dimension (approx.)WDH

65 x 44 x 41cm

Standards

SATRA TM103

Inquiry Now

Detailed Description

Inquiry Now

Application of Elastic Tape Fatigue Testing Machine

This instrument is designed to measure the elongation and repeatability of elastic bands, cloths and other elastic materials at maximum stretch.

Elastic Tape Fatigue Testing Equipment Purpose

The instrument is designed for measuring the extensibility and repeatability of elastic tape, cloth and other elastic materials under the maximum stretch.

Principle of Elastic Tape Fatigue Tester

Using ecceantric wheel to conduct repeating movement that stretches the elastic material to the maximum extension. Periodically, check and inspect the condition of material. Stop the test when the specimen is suffered severe abrasion more than the expectation, or until the counter reaches a set value.
